SS304/316 Hygienic Tri-Clamp 4 Way Sanitary Plug Valve

JN-PV-23 1009
Size：1/2" - 4" (DN15 - DN100)
Grade：304/316L Stainless Steel (hygienic food/pharma grade)
Standard：3A, SMS, DIN, ISO, FDA, GMP
Working pressure: 0 - 1.6 MPa
Test pressure: 2.4 MPa
Temperature Range：-15℃ - 170℃
seals: Food/Pharma-grade PTFE, EPDM, Silicone (biocompatible, non-toxic)
Quantity:
Contact Now
SS304/316 Hygienic Tri-Clamp 4 Way Sanitary Plug Valve

OurSS304/316 Hygienic Tri-Clamp 4 Way Sanitary Plug Valve is a high-precision four-way Sanitary Valve with tri-clamp connection, specially applied to the multi-branch confluence, multi-directional diversion and media switching positions of hygienic fluid pipelines. It is mainly used for on-off and multi-path flow control of sterile fluid, pharmaceutical raw materials, food slurry and dairy products, with integrated four-way flow channel design to meet complex pipeline layout and multi-directional media transmission needs of high-hygiene production lines.

OurHygienic Tri-Clamp 4 Way Sanitary Plug316 Valveis vastly different from ordinary plug valves in structural design and connection mode: it features a four-way flow channel and quick tri-clamp connection instead of single/three-way structure and thread connection, with a fully polished inner cavity. Compared with other manufacturers’ products, our valve has precision-machined plug core and seamless forging body, better multi-path sealing performance, faster disassembly and assembly, and fully meets FDA biocompatibility requirements for strict sterile production.


Accessories

 Component & Material Table
  • Valve Body & Plug Core：304/316L Stainless Steel (hygienic-grade integral forging, no welding seam, mirror polished)
  • Sealing Component：PTFE/EPDM/Silicone (pharma/food-grade, high temperature & corrosion resistance, biocompatible)
  • Valve Stem：304/316L Stainless Steel (hygienic polishing, anti-rust, wear-resistant, torque-resistant)
  • Manual Handle：304 Stainless Steel (ergonomic, 90° quick rotation, detachable for sterilization)
  • Tri-Clamp Ferrule：304 Stainless Steel (standard sanitary grade, precision casting, quick fit)
Product Parameter Details
  • Material：All wetted parts are 304/316L hygienic stainless steel + FDA-certified sealing materials, non-toxic, no media adsorption
  • Structure Form：Four-way integrated flow channel, tri-clamp quick connection, integral forging body, inner cavity no dead angle
  • Pressure Rating：Working pressure 0-1.6MPa, test pressure 2.4MPa, stable pressure resistance in multi-path media transmission, no leakage
  • Function：Four-way media diversion, confluence, on-off and switching integration, one valve for multi-path flow control
  • Grade Classification：Hygienic grade (meets FDA, GMP, 3A standards), suitable for biopharmacy sterile production and food safe processing
  • Specification Match：Compatible with 3A/SMS/DIN/ISO international sanitary tri-clamp standards, fit standard hygienic pipeline ferrule
  • Certification Grade：Hygiene Class I (sterile production level), Safety Class IP66 (dustproof, waterproof, adapt to clean workshop)
  • Installation Direction：Horizontal/vertical optional, flexible installation for complex pipeline layout, no media flow limitation
  • Customization Service：Customizable size (1/2"-4"), sealing material, handle type, tri-clamp size, small batch sample customization supported
SS304/316 Hygienic Tri-Clamp 4 Way Sanitary Plug Valve

Feature (F)、Advantage (A)、Benefit (B)
  1. Four-way Flow Design:
  • F: Adopts integrated four-way flow channel and precision-machined plug core, realizing multi-directional media diversion/confluence/switching
  • A:One valve replaces multiple single/three-way valves, meets complex pipeline multi-path control needs, smooth media flow without stagnation
  • B: Reduces pipeline valve procurement and installation costs, simplifies complex pipeline layout, improves production line space utilization
  1. Tri-Clamp Connection:
  • F: Equipped with 3A standard sanitary tri-clamp ferrule, quick plug-in connection structure without additional fasteners
  • A: Realizes 30s quick disassembly and assembly, no tool required, good concentricity after installation, no medium accumulation at interface
  • B: Shortens pipeline maintenance and sterilization time, improves clean workshop operation efficiency, avoids secondary pollution from disassembly
  1. Hygienic Forging Body:
  • F: 304/316L hygienic integral forging valve body, inner cavity mirror polishing (Ra≤0.6μm), no welding seam no dead angle
  • A:Zero medium residue, easy for CIP/SIP online sterilization, strong corrosion resistance, meets strict sterile production requirements
  • B: Eliminates bacterial breeding hidden danger, ensures food/pharma product safety, complies with global sanitary certification standards
  1. Multi-path Sealing:
  • F: FDA-certified food/pharma-grade sealing components with multi-point precision sealing structure, matching four-way plug core
  • A: High-precision multi-path sealing, no media cross-contamination and leakage under rated pressure, sealing parts anti-aging and high temperature resistant
  • B:Prevents media waste and cross-contamination, reduces sealing part replacement frequency, saves production line maintenance costs
  1. Sterile Operation:
  • F:Detachable ergonomic stainless steel handle + full wetted parts hygienic polishing, no dead angle for dirt accumulation
  • A:Handle detachable for independent sterilization, easy manual operation with 90° quick switch, no hand contact with media flow channel
  • B:Adapts to GMP sterile operation requirements of clean workshop, reduces worker operation difficulty, ensures the sterility of production process

SS304/316 Hygienic Tri-Clamp 4 Way Sanitary Plug Valve

Interface Mode：Sanitary tri-clamp connection (3A/SMS/DIN/ISO standard), flange connection customizable
Production & Processing Method：CNC five-axis precision machining, integral forging forming, mirror polishing
Surface Treatment：Inner cavity super mirror polishing (Ra≤0.6μm), outer surface electrolytic polishing/passivation
Raw Material Processing Method：Hygienic-grade stainless steel integral forging (no casting, one-piece molding)
Operation Mode：Manual (ergonomic stainless steel handle, 90° quick rotation), pneumatic/electric actuation customization supported
Seal Ring Material Options：FDA-certified PTFE, food/pharma-grade EPDM, medical silicone
Sealing Method：Multi-point precision compression sealing, plug core and valve body tight fit, zero cross-contamination
