Food Grade Stainless Steel Thread Sanitary CPM valve

JN-CPMSQ-23 1003
Size: 1/2" – 4" (DN15 – DN100)
Material Grade: 304 / 316L (food-grade)
Compliant Standards: 3A, SMS, DIN, ISO, FDA, GMP
Operating Pressure: 0 – 1.6 MPa
Test Pressure: 2.4 MPa
Temperature Range: -20℃ to 150℃
Seal Options: Food-grade PTFE, EPDM, Silicone
Quantity:
Contact Now
Food Grade Stainless Steel Thread Sanitary CPM valve

OurFood Grade Stainless Steel Thread Sanitary CPM Valve is a compact hygienic control valve Stainless Steel valve Food Grade valve equipped with standard threaded ends, widely used in small and medium-sized food-grade fluid pipelines. It is mainly installed in processing lines, filling equipment and transfer systems to provide reliable on-off and flow control for edible liquids, beverages, dairy products and clean aqueous media. The threaded structure enables easy installation and removal without complex tools, making it highly suitable for modular and compact hygienic production setups.

OurFood Grade Stainless Steel Thread Sanitary CPM Valve is uniquely designed for food applications with a focus on safety, compactness and convenient installation, which sets it apart from common large-size sanitary valves. Unlike clamp-type or welded models, this valve features standard precision threads that allow fast assembly and disassembly while maintaining full hygiene and sealing performance. All wetted parts use food-grade 304/316L stainless steel with a crevice-free polished interior to prevent residue and bacterial growth. Compared with other similar valves, our model provides better durability, higher corrosion resistance, more stable sealing and stronger compatibility with standard threaded sanitary pipelines. It fully meets 3A, FDA and GMP requirements, making it a cost-effective and reliable choice for food, beverage and small-scale hygienic processing systems.


Accessories

 Component & Material Table
  • Valve Body & Core：304/316L Stainless Steel (food-grade forging, smooth interior)
  • Seals：PTFE, EPDM, Silicone (food-grade, high-temperature, long-life)
  • Thread Ends：304/316L Stainless Steel (standard hygienic thread)
  • Stem：304/316L Stainless Steel (precision machined, corrosion-resistant)
Product Parameter Details
  • Material：Full stainless steel wetted parts, food-grade certified, non-toxic
  • Structure Form：Threaded connection, compact structure, no dead corners
  • Pressure Rating：Working 0–1.6 MPa, test 2.4 MPa, stable and reliable
  • Function：On-off control, flow regulation, anti-leakage for food systems
  • Grade Classification：Food-grade hygienic level, compliant with 3A, FDA, GMP
  • Specification Match：3A, SMS, DIN, ISO threaded standards compatible
  • Certification Grade：Crevice-free, mirror polished, easy to clean
  • Installation Direction：Horizontal / vertical mounting acceptable
  • Customization Service：Sizes, seals, thread types available on request
Food Grade Stainless Steel Thread Sanitary CPM valve

Feature (F)、Advantage (A)、Benefit (B)
  1. Food Grade Safe:
  • F: Full 304/316L food-grade stainless steel body
  • A:Non-toxic, corrosion-resistant, no contamination to food media
  • B: Ensures food safety and meets processing certification demands
  1. Thread Quick Install:
  • F: Standard precision hygienic thread connection
  • A: Easy assembly and disassembly without extra tools
  • B: Reduces installation time and labor cost
  1. Stable Sealing:
  • F: Precision core fit with food-grade sealing components
  • A:Long-term tight sealing, no internal or external leakage
  • B: Prevents product loss and ensures production stability
  1. Hygienic Flow Path:
  • F: Crevice-free mirror polishing interior
  • A: No residue buildup, easy to clean and sterilize
  • B:Lowers bacteria risk and maintains high hygiene level
  1. Compact Durable:
  • F:Compact structure with rugged forged body
  • A:Space-saving, long service life, stable in daily use
  • B:Ideal for small systems, lowers maintenance cost

Food Grade Stainless Steel Thread Sanitary CPM valve

Interface Mode：Sanitary threaded connection (3A/SMS/DIN/ISO)
Production & Processing Method：CNC machining, integral forging, mirror polishing
Surface Treatment：Internal mirror polish, external electro-polish / passivation
Raw Material Processing Method：Forged 304/316L stainless steel
Operation Mode：Manual (standard), pneumatic/electric actuation customizable
Seal Ring Material Options：Food-grade PTFE, EPDM, Silicone
Sealing Method：Precision compression sealing, zero leakage for food applications
