Stainless Steel Sanitary Food Grade Tri-Clamp Concentric Pipe Fitting Reducer

JN-FT-23 6019
Size: 1/2"–4" (custom sizes available)
Grade: SS304 / SS316L (food-grade)
Standard: 3-A, DIN 11850, SMS, ISO
Working pressure: Up to 10 bar (145 psi)
Test pressure: 15 bar (217 psi)
Temperature Range: -20°C to 120°C for EPDM; -30°C to 200°C for Viton
PTFE seals: Available, rated -200°C to 260°C
Viton seals: Available, rated -30°C to 200°C
Quantity:
Contact Now
Recommend Products
Stainless Steel Sanitary Food Grade Tri-Clamp Concentric  Pipe Fitting  Reducer

Stainless Steel Sanitary Food Grade Tri-Clamp Concentric Pipe Fitting Reduceris a hygienic stainless steel concentric reducer Hygienic fitting with tri-clamp connections,made from food-grade 304/316L stainless steel. It is installedbetween two pipes of different diametersinfood, beverage, pharmaceutical, and dairy piping systems,where it provides a smooth concentric transitionto reduce flow resistance, avoid turbulence, and eliminate dead space for clean fluid transfer.Stainless steel reducer  Types vary by size (1/2"–4"), material grade, and compliance with standards like 3-A, DIN, SMS,and ISO, to meet diverse hygienic process needs.

Our Stainless Steel Sanitary Food Grade Tri-Clamp Concentric Pipe Fitting Reducer is specially designed for hygienic fluid systems, featuring mirror polishing, crevice-free structure, and tri-clamp quick connection, which is far superior to ordinary industrial reducers; it effectively avoids material residue and ensures safe, clean delivery infood, beverage, dairy, and pharmaceutical applications.Made from high-quality 304/316L stainless steel with strict CNC machining and stable sealing performance, our products outperform competitors with higher dimensional accuracy, better corrosion resistance, stronger durability, and wider compatibility,fully meeting strict hygienic standards and long-term reliable operation requirements.


Accessories

 Component & Material Table
  • Reducer Body:304/316L Stainless Steel (sanitary-grade forging)
  • Gasket Seals: PTFE/EPDM/Viton (food-grade, corrosion-resistant)
  • Tri-Clamp Fittings:304/316L Stainless Steel (polished finish)
Product Parameter Details
  • Material: Main body: 304/316L stainless steel; Seals: food-grade PTFE/EPDM/Viton; Clamps: 304/316L stainless steel
  • Structure Form: Standard: concentric transition, tri-clamp quick-install; Optional: custom length, special surface finish
  • Pressure Rating: PN10/150PSI (working pressure); Test pressure: 1.5× working pressure
  • Function: Smooth pipe diameter transition, reduce flow resistance, eliminate dead space, ensure hygienic fluid transfer
  • Grade Classification:Hygiene grade (3A/DIN 11851); Suitable for food, beverage, pharmaceutical, and cosmetic industries; no industrial-grade option
  • Specification Match: Standards: DIN (German), SMS (Swedish), 3A (American), ISO (international); Size range: 1/2"–4"(custom sizes available)
  • Certification Grade: Hygiene certification: 3A, FDA; Safety certification: CE, ISO 9001
  • Installation Direction: Horizontal/vertical installation (no flow direction restriction); tri-clamp connection for easy operation
  • Customization Service:Custom size (5"+), special seal material (Viton), jacketed structure, sample support for testing
Stainless Steel Sanitary Food Grade Tri-Clamp Concentric  Pipe Fitting  Reducer

Feature (F)、Advantage (A)、Benefit (B)
  1. Raw Material:
  • F: 100% virgin 304/316L stainless steel (sanitary-grade forging); food-grade PTFE/EPDM/Viton gaskets
  • A: Superior corrosion resistance; zero material contamination; full compliance with strict hygienic standards
  • B: Safe for food, pharmaceutical & dairy applications; eliminates media pollution risks; adapts to harsh chemical working conditions
  1. Processing Technology:
  • F: Full internal/external mirror polishing (Ra≤0.8μm); one-piece forging; no welding seams or dead corners
  • A: No medium residue; effortless CIP/SIP cleaning & sterilization; exceptional structural durability and pressure resistance
  • B: Cuts cleaning time and labor costs; meets all hygienic process requirements; prevents pipeline blockages and leakage failures
  1. Structure Feature:
  • F: Concentric bore design; tri-clamp quick-install connection; uniform wall thickness transition
  • A: Smooth fluid transition with minimal flow resistance; 50% faster assembly/disassembly; avoids turbulence and material accumulation
  • B: Optimizes pipeline flow efficiency; reduces installation downtime; adapts to compact sanitary pipeline layouts seamlessly
  1. Core Accessory Feature:
  • F: CNC-machined clamp ends; strict tolerance control (±0.05mm); standardized fitting with universal tri-clamp systems
  • A: Perfect alignment with pipes/clamps; leak-free connection; high compatibility with global sanitary pipe standards
  • B: Lowers installation error rates; eliminates the need for on-site reworking; ensures stable interconnection with existing pipeline components
  1. Seal Ring Feature:
  • F: Molded food-grade gaskets with anti-extrusion design; multi-material compatibility (PTFE/EPDM/Viton)
  • A: Excellent sealing performance; wide temperature adaptability; resistance to chemical corrosion and aging
  • B: Adapts to -20°C~260°C working conditions; prevents medium leakage; extends service life and reduces gasket replacement costs

Stainless Steel Sanitary Food Grade Tri-Clamp Concentric  Pipe Fitting  Reducer

Interface Mode：Tri-clamp quick-install (DIN/SMS/3A/ISO standard); customizable welded/threaded ends
Production & Processing Method：Full CNC precision machining; one-piece forging shaping; no welding seams or dead corners
Surface Treatment：Inner/outer cavity mirror polishing (Ra ≤ 0.8μm); outer surface electrolytic polishing/passivation; sanitary-grade anti-corrosion treatment
Raw Material Processing Method：Reducer body: 304/316L stainless steel forging (high structural density, no porosity); gaskets: precision molded
Operation Mode：Passive fitting (no actuation required); tri-clamp connection for quick assembly/disassembly
Seal Ring Material Options：Food-grade PTFE, EPDM, Viton (FKM); FDA/3A certified for hygienic applications
Sealing Method：Compression seal (gasket compressed between tri-clamp ends); precision-machined sealing faces for leak-free performance
