Stainless Steel Sanitary Aseptic Sample Sampling Valve

JN-SPV2008
Size: DN6 – DN15
Material Grade: SS304 / 316L (sanitary grade)
Compliant Standards: 3A, SMS, DIN, ISO, FDA, GMP
Operating Pressure: 0 – 1.0 MPa
Test Pressure: 1.5 MPa
Temperature Range: -10℃ to 80℃
Seal Options: Food-grade EPDM, Silicone, PTFE
Quantity:
Contact Now
Recommend Products
Stainless Steel Sanitary Aseptic Sample Sampling Valve

OurStainless Steel Sanitary Aseptic Valve is a professional sterile sampling valve used in high-hygiene pipelines for safe, contamination-free sample extraction. It provides fully enclosed sampling for liquids, syrups, milk, beverages and pharmaceutical fluids, effectively preventing external bacteria and ensuring sample authenticity. Compact and reliable, it is widely used in strict hygienic and aseptic production environments.

OurStainless Steel Sanitary Aseptic Sample Valve is specially built for aseptic conditions, making it significantly different from ordinary sampling valves. It features a fully enclosed, dead-angle-free structure that completely isolates the medium from the outside environment during sampling, avoiding pollution and ensuring test accuracy. All wetted parts are made of 304/316L stainless steel with mirror polishing, supporting CIP/SIP cleaning and long-term sterile use. Compared with similar products, our valve offers higher sealing reliability, smoother operation, easier maintenance and stronger durability. It fully complies with 3A, FDA and GMP standards, making it the preferred choice for aseptic sampling in food, beverage, dairy and pharmaceutical industries.


Accessories

 Component & Material Table
  • Valve Body & Wetted Parts：SS304/316L Stainless Steel (sanitary forging, mirror polished)
  • Sealing Parts：EPDM, Silicone, PTFE (food-grade, high-temperature, aseptic)
  • Sampling Nozzle：SS304 (smooth, crevice-free, easy cleaning)
  • Connection Ends：SS304/316L (sanitary clamp or thread)
Product Parameter Details
  • Material：Full stainless steel wetted parts, hygienic & non-toxic
  • Structure Form：Aseptic closed structure, crevice-free interior
  • Pressure Rating：Working 0–1.0 MPa, test 1.5 MPa, stable and safe
  • Function：Aseptic sampling, sterile testing, closed extraction
  • Grade Classification：Sanitary & aseptic level, for food, pharma, beverage, dairy
  • Standard：3A, SMS, DIN, ISO compliant
  • Hygiene：Mirror polished, CIP/SIP suitable
  • Installation Direction：Horizontal / vertical mounting allowed
  • Customization Service：Size, connection, seal material available
Stainless Steel Sanitary Aseptic Sample Sampling Valve

Feature (F)、Advantage (A)、Benefit (B)
  1. Aseptic Sampling:
  • F: Fully enclosed aseptic structure
  • A:Isolates medium from outside, no contamination
  • B: Ensures sample validity and production safety
  1. Hygienic Flow Path:
  • F: Crevice-free mirror polishing
  • A: No residue, easy to clean and sterilize
  • B: Meets high-level hygienic standards
  1. Strong Sealing:
  • F: Precision sealing with food-grade gaskets
  • A:No leakage during sampling or standby
  • B: Prevents waste and cross-contamination
  1. Full Stainless Steel:
  • F: SS304/316L hygienic construction
  • A: Corrosion-resistant, long service life
  • B:Suitable for continuous hygienic use
  1. Compact Size:
  • F:Mini design (DN6–DN15)
  • A:Space-saving, fits small pipelines
  • B:Ideal for aseptic sampling points

Stainless Steel Sanitary Aseptic Sample Sampling Valve

Interface Mode：Sanitary clamp / thread (3A/SMS/DIN/ISO)
Production & Processing Method：CNC machining, forging, mirror polishing
Surface Treatment：Internal mirror polish, external electro-polish / passivation
Raw Material Processing Method：Forged SS304/316L stainless steel
Operation Mode：Manual, smooth and safe control
Seal Ring Material Options：Food-grade EPDM, Silicone, PTFE
Sealing Method：Compression sealing, zero leakage
