Stainless Steel Electric pressure water modulating Regulating Valve

JN-GTVSQ-23 1001-16
Size: DN15–DN100.
Grade:Industrial/Sanitary optional.
Standard: BSP/NPT/DIN/ANSI compatible.
Working pressure: PN10–PN40.
Test pressure: 1.5× rated.
Temperature range: -10°C to 120°C.
Seals: PTFE for chemical resistance, Viton for high temperature and durability.
Quantity:
Contact Now
Stainless Steel Electric pressure water modulating Regulating Valve


Stainless Steel Electric pressure water regulating valve is aprecision water flow and Pressure Regulating Valve designed forthreaded pipeline systems. It is typically installed on branch lines, pump outlets, pressure balancing sections, or terminal water distribution pipelines, where it is used to maintain stable double-pressure zones and regulate flow automatically. The valve ensures balanced upstream and downstream pressure, prevents pressure fluctuation, and protects sensitive equipment. Common types includemanual threaded regulating valves, hydraulic pilot-controlled double pressure valves, precision needle-type regulators, and compact inline threaded control valves, suitable for industrial water supply, HVAC systems, irrigation networks, and hygienic processing pipelines requiring accurate flow and pressure management.

Compared with ordinary regulating valves,Stainless Steel Electric pressure water modulating Regulating Valve is designed fordual-pressure balance and precise flow stabilization, while standard valves usually providesingle-parameter manual adjustment with less dynamic control. It offerscompact threaded installation, fast response to pressure variation, and stable downstream regulation, making it ideal for space-limited water systems. Compared with other manufacturers, our valve features precision CNC machining, full stainless steel corrosion-resistant construction, optimized internal flow channels, and high-performance PTFE/Viton sealing, resulting in higher regulation accuracy, reduced leakage risk, longer service life, and more reliable performance in industrial, HVAC, and hygienic pipeline applications.



Accessories

 Component & Material Table
  • Valve Body – SS304 / SS316L forged or precision cast stainless steel
  • Valve Core / Plug – SS316 / hardened stainless steel
  • Stem– Stainless steel precision machined shaft
  • Spring / Balancing Components – Stainless steel alloy spring
  • Pilot / Pressure Chamber – Stainless steel or brass (optional)
  • Sealing Rings – PTFE / Viton / EPDM / NBR
  • Bonnet / Cover – Stainless steel machined component
  • Threaded Ends – Stainless steel integrated threads
Product Parameter Details

  • Material：Main body: 304/316/316L stainless steel; Valve stem & regulating plug: SS316L; Double pressure spring: stainless spring steel; Seals: PTFE/EPDM/FKM/Silicone; Threaded connection: BSP/NPT stainless steel
  • Structure Form：Standard: inline threaded regulating structure with double pressure spring balance; Internal precision flow control core; Optional: jacketed structure for thermal media control, anti-water hammer design, fine adjustment handwheel or locking cap
  • Pressure Rating：PN10/PN16/PN25; Working pressure: 0.1–2.5 MPa (adjustable range optional); Test pressure: 1.5× working pressure; Temperature range: -10°C to 180°C (depending on seal material)
  • Function：Double pressure stabilization and flow regulation; Outlet pressure control; Flow rate adjustment; Back pressure balancing; Anti-vibration and stable discharge for water or clean process media
  • Grade Classification：Sanitary grade (food, beverage, pharmaceutical water systems); Chemical process grade (mild corrosive fluids); Industrial water treatment grade; High-purity process optional
  • Specification Match：Thread standards: BSP, BSPT, NPT, G; Design standards: DIN, ANSI, ISO; Size range: DN15–DN100 (1/2"–4")
  • Certification Grade：Hygiene compliance: FDA-approved seal material optional; Quality certification: ISO 9001; Safety certification: CE; Pressure equipment compliance available upon request
  • Installation Direction：Horizontal or vertical installation; Inline threaded mounting; Flow direction marking recommended; Accessible adjustment position required
  • Customization Service：Custom sizes (DN100+); Special seal materials (FFKM, Viton, high-temp PTFE); Extended pressure range design; OEM structure modification; Sample support for testing and validation

Stainless Steel Electric pressure water modulating Regulating Valve

Feature (F)、Advantage (A)、Benefit (B)

     1. High-Strength Stainless Steel Precision Structure

  • F: SS304/SS316 forged body, CNC precision machining, reinforced threaded connection and durable valve core design.
  • A: Higher corrosion resistance, improved structural stability and enhanced pressure endurance.
  • B: Longer service life, reduced maintenance cost and reliable performance in demanding water systems.

     2. Dual-Pressure Balanced Regulating Mechanism

  • F: Special double-pressure hydraulic balancing structure with precision internal control components.
  • A: Stable upstream/downstream pressure regulation, accurate flow control and reduced pressure fluctuation.
  • B: Protects pumps and pipelines, improves system stability and minimizes operational risks.

     3. Compact Threaded Inline Design

  • F: Integrated threaded structure with compact body, optimized internal flow channel and streamlined design.
  • A: Easy installation in limited spaces, reduced turbulence and lower pressure loss.
  • B: Faster installation, improved pipeline efficiency and reduced overall system energy consumption.

     4. Advanced Surface Finishing & Manufacturing Process

  • F: Full polishing, precision assembly, hygienic internal surface finishing and anti-corrosion treatment.
  • A: Reduced scaling, improved fluid cleanliness and enhanced durability in water applications.
  • B: Easier maintenance and cleaning, longer maintenance intervals and consistent system performance.

     5. High-Performance Sealing System

  • F: PTFE / Viton / EPDM sealing options with optimized sealing geometry and wear-resistant components.
  • A: Strong leak-proof performance, enhanced temperature resistance and extended sealing lifespan.
  • B: Lower leakage risk, reduced downtime and dependable long-term sealing stability for customers.

Stainless Steel Electric pressure water modulating Regulating Valve

Connection Types:Threaded connections including BSP, BSPT, and NPT are standard. Optional sanitary clamp, welded ends, or adapter-compatible flange connections (ANSI / DIN / JIS) can be provided for different pipeline systems.
Manufacturing & Processing Methods:CNC precision machining, automatic turning and milling, drilling, welding assembly, bending/forming of auxiliary pipelines, and precision internal component processing ensure accurate regulation performance.
Surface Treatment Methods:Mechanical polishing, electro-polishing, pickling and passivation, sandblasting or matte finishing, and optional mirror polishing for hygienic applications improve corrosion resistance and surface cleanliness.
Raw Material Processing Methods:Forged stainless steel valve bodies for high strength, precision casting for complex components, machined bar stock for internal parts, and stamping or plate pressing for covers and auxiliary accessories.
Operation Methods:Manual adjustment as standard, with optional pneumatic pilot control or electric actuator-assisted monitoring/control depending on system automation requirements.
Sealing Material Options:PTFE, Viton (FKM), EPDM, NBR, and optional silicone seals for specific temperature or hygienic applications.
Sealing Structures:Center sealing design, hydraulic balanced sealing structure, diaphragm or piston sealing systems, and soft-seated sealing configurations to ensure stable pressure control and reliable leak prevention.
