Stainless Steel 2" Electric Pressure Automatic Modulating Globe Control Regulating Valve

JN-GTVSQ-23 1001-1
Size: DN15–DN100.
Grade: SS304/SS316L.
Standard: DIN, SMS, 3A.
Working pressure: 0.1–1.6
MPa. Test pressure: 2.4 MPa.
Temperature Range: -20°C to 180°C.
PTFE seals: corrosion resistance.
Viton seals: high-temperature sealing reliability.
Quantity:
Contact Now
Stainless Steel 2"Electric Pressure Automatic Modulating Globe Control Regulating Valve

TheStainless Steel Pressure Regulating Valve is the core flow control equipment for high-cleanliness flexible applications such as biopharmaceutical laboratory small-scale trials, pilot scale-up, modular mobile clean liquid preparation systems, and small-batch production of sterile medical aesthetics preparations. It is specifically designed for scenarios requiring no-hot-work quick disassembly/assembly in clean areas, multi-product changeover, and manual precise flow regulation. The valve is integrally precision forged from AISI 304/316L pharmaceutical-grade stainless steel. It features a high-precision manual adjustment mechanism with scale and locking, a aseptic quick-install integrated valve body, and FDA-certified quick-install dedicated sealing components. The clamp is forged integrally with the valve body, and the entire flow path undergoes ultra-mirror electrolytic polishing, eliminating welding dead legs and media retention. It is the essential equipment for precise flow regulation, rapid changeover, and compliant production in high-cleanliness flexible manufacturing scenarios.globe control valve

TheStainless Steel automatic regulating valve achieves comprehensive upgrades in adjustment accuracy, disassembly/assembly stability, and aseptic suitability.

  • Conventional welded manual control valves cannot adapt to modular production lines; hot work in clean areas easily generates oxidation contamination, and changeover is difficult.

  • Ordinary quick-install manual valves lack precise scales, allowing only rough adjustment with repetitive deviation exceeding 15%. Without a locking device, flow drift is common.

  • Conventional quick-install valves have clamps and valve bodies welded separately, prone to deformation and leakage after repeated disassembly/assembly. The flow path has step dead legs, making cleaning validation difficult.

This product features an integrally formed clamp and valve body, a precise fine-tuning mechanism with scale, a dead-leg-free full flow path, and can withstand tens of thousands of disassembly/assembly cycles, perfectly meeting the flexible production requirements of rapid changeover and small-batch multi-product in clean areas.

TheStainless Steel 2"Electric Pressure Automatic Modulating Globe Control Regulating Valve mainly consists of five modules: an integrally forged quick-install valve body, a manual adjustment mechanism with scale and locking, a linear fine-tuning valve core assembly, a quick-install dedicated aseptic sealing system, and standard quick-install connection ends.

During operation, rotating the handwheel with a precise scale drives the stem to move linearly with high precision, which in turn drives the valve core to adjust the flow cross-sectional area, achieving infinitely variable manual precise flow regulation from micro-flow to rated flow. After adjustment, the locking mechanism secures the valve position, preventing flow drift.

In the closed position, the valve core and seat come into zero-gap mirror contact, achieving fully closed aseptic sealing. The entire flow path has smooth arc transitions without dirt-trapping gaps. CIP/SIP online sterilization can be performed without disassembly, or the valve can be quickly disassembled for offline cleaning, fully meeting GMP and ASME BPE compliance requirements.

Accessories

 Component & Material Table
  • Seal Material：FDA-certified modified PTFE quick-install dedicated seal; EPDM,food-grade silicone optional; embedded groove anti-misalignment design
  • Body Material：AISI 304/316L pharmaceutical-grade stainless steel; 316L is therecommended material for aseptic scenarios; special alloysavailable on request
  • Installation Adaptation：Standard 3-A/ASME BPE quick-install clamp connection; noinstallation angle restriction; no hot work, ready to use; customspecial specifications available
  • Hygiene Level：Inner flow path Ra≤0.3um; sealing surface Ras0.18um; quick-install clamp sealing surface Ras0.2um; full flow path with nostep dead legs
Product Parameter Details
  • Applicable Grade：Highest pharmaceutical hygienic grade; meets FDA/3-A/GMP/ASME BPE standards; suitable for biopharmaceutical pilotscale, modular clean production line scenarios
  • Core Function：Manual precise flow regulation for aseptic pipelines; valveposition indication with scale and locking; zero-leakage asepticsealing; supports CIP/SIP online sterilization; quickdisassembly/assembly for frequent changeover
  • Structure Type：Integrally precision forged clamp and valve body; high-precisionmanual adjustment mechanism with scale and locking; linear fine-tuning valve core; straight-through dead-leg-free flow path; withvalve position scale indication and anti-touch locking device
  • Pressure & Temperature：Short-term SIP sterilization <160°C; Long-term workingtemperature -20°C~120°C; Rated working pressure <1.OMPa

Digital advantages

  • Scale-Flow Intelligent Matching: Comes with a dedicated flow scale lookup table. Scan a QR code to obtain flow parameters for the corresponding working condition. Improves adjustment efficiency by 3 times compared to conventional manual valves. Completely solves the pain point of no reference and repeated trial adjustment.

  • Full-Cycle Compliance Traceability: Can be linked to production batches. Records adjustment parameters, disassembly/assembly times, sterilization data. Generates tamper-proof traceability archives. Storage period exceeds 10 years. One-click export of GMP audit reports. Meets audit trail requirements.

  • Intelligent Maintenance Reminder: Based on disassembly/assembly times and usage duration, intelligently predicts seal wear cycles and maintenance points. Pushes maintenance reminders in advance. Prediction accuracy exceeds 98%. Reduns故障停机率 by more than 90%.

  • Modular Production Line Digital Adaptation: Supports integration with modular production line digital management systems. Synchronizes valve position parameters and changeover records. Seamlessly connects to factory MES systems. Adapts to the digital management needs of flexible smart factories.

  • Full-Scenario Industrial Interoperability: Supports mainstream industrial communication protocols such as 4-20mA, Modbus, PROFINET, OPC UA, and Hart. Meets factory requirements.

Stainless Steel 2"Electric Pressure Automatic Modulating Globe Control Regulating Valve

Feature (F)、Advantage (A)、Benefit (B)
  1. Raw Material:
  • F:Valve body and quick-install clamp are integrally precision forged from AISI 316Lpharmaceutical-grade stainless steel from the same billet. No splicing or welding. Full materialtraceability.
  • A:: The integrally formed clamp has no welding stress and no intergranular corrosion. It doesnot deform or crack after repeated disassembly/assembly. It is acid and alkali resistant andwithstands thousands of high-temperature sterilization cycles without deformation.
  • B:  Solves the pain point of leakage-prone conventional welded quick-install valves afterdisassembly/assembly. Meets FDA/GMP compliance requirements. Significantly extends productservice life and reduces compliance audit risk.
  1. Processing Technology:
  • F:  Integrally forged valve body with no weld seams. The flow path undergoes ultra-mirror +electrolytic double polishing. Inner flow path Ras0.3um. Clamp dimensions strictly comply with3A/ASME BPE standards.
  • A:  Ultra-smooth flow path with no media adhesion and no cleaning blind spots. Clamp fitprecision reaches the micron level. Seals do not shift or wear after repeateddisassembly/assembly, preventing microbial growth.
  • B: Reduces cross-contamination risk. Simplifies cleaning validation process. Changeovercleaning time reduced by more than 60%. Ensures aseptic compliance for multi-batchproduction.
  1. Structure Feature:
  • F: Compact manual adjustment mechanism with scale and locking. Straight-through dead-leg
    free flow path. Valve position scale precisely corresponds to flow value. Built-in anti-touchlocking device.
  • A: Adjustable precision is visualizable. Valve position control is accurate without drift.Disassembly/assembly does not require removing the adjustment mechanism. One person cancomplete installation and debugging. No leakage risk.
  • B:  Avoids the pain points of conventional manual valves (no reference for adjustment, easydrift). Single batch changeover time reduced by 80%. Suitable for pilot plants with frequentchangeover. Reduces labor costs.
  1. Core Accessory Feature:
  • F:  Valve core features customized equal percentage flow characteristic design. Adjustmenthandwheel has micron-level feed scale. Each valve undergoes individual flow calibration beforedelivery. Comes with a one-to-one flow calibration certificate.
  • A: Flow changes linearly and uniformly during manual adjustment. No sudden flow changes atsmall openings. No sluggish response at large openings. Scale values correspond precisely toactual flow. No repeated trial adjustment needed.
  • B:Significantly reduces process deviation from manual adjustment. Ensures flow consistencyacross multiple batches. Reduces material loss from trial adjustments. Meets GMP processstability compliance requirements.
  1. Seal Ring Feature:
  • F: FDA-certified modified PTFE quick-install dedicated seal. Embedded groove positioning anti-detachment structure. Built-in automatic wear compensation function.
  • A: Seal does not shift or get damaged during disassembly/assembly. Provides 360° dead-leg-free sealing contact. Maintains zero leakage after thousands of disassembly/assembly cycles.
  • B: Eliminates the pain point of seal damage and leakage after disassembly/assembly ofconventional quick-install valves. Extends seal service life. Reduces spare part replacementcosts.

Stainless Steel 2"Electric Pressure Automatic Modulating Globe Control Regulating Valve

Nominal Diameter：DN10 ~ DN100 (3/8"~ 4")
Maximum Working Pressure：10bar (1.OMPa), hydrostatic test pressure 1.5MPa
Body Material：AISI 304, AISI 316L Pharmaceutical Grade Stainless Steel
Seal Material：Modified PTFE (standard), EPDM/Silicone (optional), FDAcertified
Connection Type：Tri-Clamp (standard, complies with 3-A/ASME BPE)
Working Temperature：Long-term: -20°C ~ 120°C; Short-term SIP:≤160°C
Surface Treatment：Ultra-mirror + electrolytic polishing, inner flow channelRas0.3um
