Stainless Steel Angle Y-type Basket Sanitary Duplex Fine Strainer

JN-STN-23 1006-1
Size: DN15-DN200, 5"/10"/20"/30" cartridge
Grade: 304/316L SS
Standard: GB, HG, ANSI, ASTM
Working pressure: 1.0-10.0 MPa
Test pressure: 1.5×WP
Temperature: -40℃ ~ 150℃
PTFE seals: -180℃ ~ 260℃, full chemical resistance
Viton seals: -20℃ ~ 200℃, good elasticity
Quantity:
Contact Now
Stainless Steel Angle Y Basket Sanitary Duplex Fine Strainer


OverviewStainless Steel Angle Strainer feature a quick-release clamp structure, are made entirely of stainless steel, and are easy to disassemble, install, and clean. They are widely used in food, pharmaceutical, and daily chemical fluid pipelines, installed at pipeline transport nodes. They primarily intercept liquid impurities and particulate matter, purifying the media quality. Common types include straight-through, Y-type, bag, and cartridge types, adaptable to different filtration precision and pipeline operating conditions.

Stainless Steel Y-type Strainer differ from ordinary filtration equipment. They feature a mirror-polished, dead-angle-free design, meeting sanitary production standards. With the quick-connect clamp structure, disassembly, maintenance, and cartridge replacement require no tools, increasing efficiency. They are resistant to acids, alkalis, and corrosion, have stronger sealing performance, and are less prone to dirt and bacteria growth. Compared to threaded and flanged connections, they are suitable for clean fluid pipelines; they offer a wider range of filtration precision options, stable pressure resistance, and are more suitable for high-standard production scenarios such as food and pharmaceutical industries.


Working Principle

TheStainless Steel Angle Y Basket Strainer mainly consists of a valve body, filter screen, clamps, and sealing gaskets. The product connects to sanitary delivery pipelines and matching fittings, relying on the clamps to secure the pipe ends for a snap-fit ​​installation, making assembly and disassembly simple and convenient. After connection, the pipeline has excellent sealing performance, with no dead spots, ensuring stable media delivery. During operation, fluid enters the chamber, the filter screen intercepts impurities and particles, and contaminants are retained within the filter body. The filtered clean media flows normally through the pipeline, effectively purifying the fluid and meeting the clean production requirements of the food and pharmaceutical industries.



Accessories

 Component & Material Table
  • Material:Mainstream 304, 316L stainless steel, corrosion resistant and rust-resistant
  • Structure:Straight-through, Y-type, bag type, jacketed insulation structure optional
  • Pressure: Standard PN16, suitable for low-pressure fluid pipelines
  • Function:Intercepts impurities, purifies media, protects pipelines
  • Product Grade: Standard sanitary grade, suitable for clean fluid conditions
  • Specifications:Compatible with DIN, 3A, ISO, American standard, German standard chuck sizes
  • Safety and Hygiene Grade: Complies with food and pharmaceutical cleanroom safety regulations
  • Installation Direction: Can be installed horizontally or vertically
  • Customization:Supports customization of size, precision, and function; samples available
  • Capacity: Classified by diameter, complete specifications and categories

Digital advantages

  • 1. Intelligent Data Monitoring: Equipped with sensor modules, it collects differential pressure and flow data in real time, accurately controlling the filter's operating status.
  • 2. Predictive Maintenance: Based on data feedback, it predicts filter clogging, providing early warnings and avoiding equipment downtime.
  • 3.Full Traceability Recording: Adapts to digital production systems, retaining filtration data to meet food and pharmaceutical traceability compliance requirements.
  • 4.Remote and Controllable Operation and Maintenance: Supports integration with IoT platforms, enabling remote status monitoring and simplifying production line operation and maintenance management.
  • 5. Standardized Digital Adaptation: Specifications and parameters are uniformly digitized, seamlessly integrating with automated and intelligent fluid production lines.
