Sanitary Stainless Steel Clamped PVC Aseptic Sampling Valve

JN-SPV1002
Size: DN6 – DN15
Material Grade: SS304/316L + PVC (sanitary & food‑grade)
Compliant Standards: 3A, SMS, DIN, ISO, FDA, GMP
Operating Pressure: 0 – 1.0 MPa
Test Pressure: 1.5 MPa
Temperature Range: -10℃ to 80℃
Seal Options: Food‑grade EPDM, Silicone, PTFE
Quantity:
Contact Now
Download directory
Recommend Products
Sanitary Stainless Steel Clamped PVC Aseptic Sampling Valve

OurSanitary Stainless Steel Clamped PVC Aseptic Sampling Valve is a professional mini-sized Sanitary Valve aseptic sampling valve Stainless Steel Valve with standard sanitary clamped connection, mainly installed on small hygienic pipelines for safe medium extraction and testing. It realizes closed, contamination-free sampling for beverages, milk, syrup, pharmaceutical fluids and other high‑hygiene media. The compact structure and PVC protective design ensure safe and stable operation in laboratory and production line sampling points.

OurSanitary Stainless Steel Clamped PVC Aseptic Sampling Valve is specially designed for small‑caliber hygienic pipelines, which makes it very different from common large‑size sampling valves. It features a fully enclosed aseptic structure to avoid contact between samples and the external environment, effectively ensuring sample authenticity and preventing bacterial contamination. The wetted parts use 304/316L stainless steel with mirror polishing, while the external PVC housing provides safe operation and anti‑scald protection. Compared with similar products, our valve offers more compact structure, higher sealing reliability, easier cleaning and better compatibility with CIP/SIP systems. The standard clamped connection allows fast installation and disassembly, and it fully complies with 3A, FDA and GMP standards, making it widely used in small‑caliber pipeline sampling for food, beverage, dairy and pharmaceutical industries.


Accessories

 Component & Material Table
  • Valve Body & Wetted Parts：SS304/316L Stainless Steel (sanitary forging, mirror polished)
  • Protective Cover： PVC (anti‑scald, safe operation, insulation)
  • Sealing Parts：EPDM, Silicone, PTFE (food‑grade, aseptic, high‑temperature resistant)
  • Sampling Nozzle：SS304 (smooth, crevice‑free, easy cleaning)
  • Clamp End：SS304 (standard sanitary connection, quick assembly)
Product Parameter Details
  • Material：Hygienic stainless steel for wetted parts, food‑grade PVC for external protection
  • Structure Form：Clamped connection, closed aseptic structure, mini‑size design
  • Pressure Rating：Working 0–1.0 MPa, test 1.5 MPa, stable and safe
  • Function：Aseptic sampling, medium testing, closed sample collection
  • Grade Classification：Sanitary & aseptic level, suitable for food, pharma, beverage, dairy
  • Standard：3A, SMS, DIN, ISO sanitary standards
  • Certification Grade：Crevice‑free, mirror polished, CIP/SIP suitable
  • Installation Direction：Horizontal / vertical mounting allowed
  • Customization Service：Size, seal material, structure can be customized
Sanitary Stainless Steel Clamped PVC Aseptic Sampling Valve

Feature (F)、Advantage (A)、Benefit (B)
  1. Aseptic Sampling:
  • F: Fully enclosed aseptic sampling structure
  • A:Prevents external contamination, ensures sample authenticity
  • B: Guarantees test accuracy and production safety
  1. Sanitary Clamp:
  • F: Standard sanitary clamped connection
  • A: Fast installation, good sealing, no dead gaps
  • B: Improves maintenance efficiency and pipeline compatibility
  1. PVC Protection:
  • F: External PVC protective housing
  • A:Anti‑scald, insulation, safe manual operation
  • B: Reduces operation risk and extends service life
  1. Hygienic Flow Path:
  • F: Crevice‑free mirror polishing interior
  • A: No residue, easy to clean and sterilize
  • B:Meets high‑level hygienic production requirements
  1. Compact Structure:
  • F:Mini‑size design (DN6–DN15)
  • A:Fits small‑caliber pipelines, space‑saving
  • B:Ideal for laboratory and compact production systems

Sanitary Stainless Steel Clamped PVC Aseptic Sampling Valve

Interface Mode：Sanitary clamped connection (3A/SMS/DIN/ISO)
Production & Processing Method：CNC machining, forging, mirror polishing
Surface Treatment：Internal mirror polish, external electro‑polish / passivation
Raw Material Processing Method：Forged SS304/316L + food‑grade PVC
Operation Mode：Manual, smooth and safe sampling control
Seal Ring Material Options：Food‑grade EPDM, Silicone, PTFE
Sealing Method：Compression aseptic sealing, zero leakage
