Sanitary Female Thread in-line extended sampling valve

JN-SPV1001
Size: DN6 – DN15
Material Grade: SS304 / 316L (sanitary food-grade)
Compliant Standards: 3A, SMS, DIN, ISO, FDA, GMP
Operating Pressure: 0 – 1.0 MPa
Test Pressure: 1.5 MPa
Temperature Range: -10℃ to 80℃
Seal Options: Food-grade EPDM, Silicone, PTFE
Quantity:
Contact Now
Download directory
Recommend Products
Sanitary Female Thread in-line extended sampling valve

OurSanitary Female Thread in-line extended sampling valve is a specialized inline sampling valve with extended stem and female thread Female valve connection, mainly used in limited-space pipelines for safe medium extraction. It enables easy reach and clean sampling for beverages, milk, syrup and Sanitary valve pharmaceutical fluids, especially suitable for insulated or deep-mounted pipeline positions. The inline structure ensures smooth flow and no dead zones during daily production.

OurSanitary Female Thread in-line extended sampling valve is uniquely designed with an extended operating stem and female thread connection, making it highly suitable for hard-to-reach pipeline positions. Unlike standard sampling valves, its extended structure allows operators to sample safely without approaching pipelines closely, improving convenience and safety. All wetted parts are made of 304/316L stainless steel with crevice-free mirror polishing, ensuring high hygiene and easy CIP cleaning. Compared with other sampling valves, our model provides better accessibility, more stable sealing, simpler operation and stronger corrosion resistance. It fully complies with 3A, FDA and GMP standards, making it widely used in food, dairy, beverage and pharmaceutical industries requiring inline sampling in compact or insulated pipeline systems.


Accessories

 Component & Material Table
  • Valve Body & Wetted Parts：SS304/316L Stainless Steel (sanitary forging, mirror polished)
  • Extended Stem：SS304 (extended design, easy operation)
  • Sealing Parts：EPDM, Silicone, PTFE (food-grade, high-temperature, long-life)
  • Female Thread End：SS304/316L (precision hygienic thread)
  • Sampling Nozzle：SS304 (smooth, crevice-free, easy cleaning)
Product Parameter Details
  • Material：Full stainless steel wetted parts, sanitary food-grade, non-toxic
  • Structure Form：In-line type, extended stem, female thread connection
  • Pressure：Working 0–1.0 MPa, test 1.5 MPa, stable and safe
  • Function：In-line sampling, extended reach, clean medium extraction
  • Grade：Sanitary grade, suitable for food, pharma, beverage, dairy
  • Standard：3A, SMS, DIN, ISO compliant
  • Hygiene：Crevice-free, mirror polished, CIP suitable
  • Installation Direction：Horizontal / vertical mounting allowed
  • Customization Service：Size, extended length, seal material available
Sanitary Female Thread in-line extended sampling valve

Feature (F)、Advantage (A)、Benefit (B)
  1. Extended Stem:
  • F: Special extended operating stem design
  • A:Easy sampling for deep / insulated pipelines
  • B: Improves operation safety and convenience
  1. Female Thread:
  • F: Standard sanitary female thread connection
  • A: Firm installation, good sealing, easy assembly
  • B: Enhances pipeline compatibility and stability
  1. In-line Structure:
  • F: In-line flow path without turbulence
  • A:Smooth medium transfer, no residue buildup
  • B: Suitable for continuous production systems
  1. Hygienic Polish:
  • F: Crevice-free mirror polishing interior
  • A: Easy to clean, no bacteria growth
  • B:Meets high-level hygienic production demands
  1. Compact Size:
  • F:Mini size (DN6–DN15) extended sampling valve
  • A:Space-saving, fits narrow installation spaces
  • B:Ideal for compact hygienic pipeline systems

Sanitary Female Thread in-line extended sampling valve

Interface Mode：Sanitary female thread (3A/SMS/DIN/ISO)
Production & Processing Method：CNC machining, forging, mirror polishing
Surface Treatment：Internal mirror polish, external electro-polish / passivation
Raw Material：Forged SS304/316L stainless steel
Operation Mode：Manual, extended stem control
Seal Ring Material Options：Food-grade EPDM, Silicone, PTFE
Sealing Method：Compression sealing, zero leakage
