Stainless Steel Sanitary 304 Cutoff valve
Grade: SS304/SS316L.
Standard: DIN, SMS, 3A.
Working pressure: 0.6–1.6 MPa.
Test pressure: 2.4 MPa.
Temperature Range: -20°C to 180°C.
PTFE seals: excellent chemical resistance.
Viton seals: high-temperature sealing durability.
Thestainless steel sanitary Cutoff valve is a hygienic fluid control valve specifically designed for the food & beverage, dairy, biopharmaceutical, beer brewing, fermentation engineering, cosmetics, purified water systems, and fine chemical industries. It is mainly used for opening, closing, and flow regulation of media in pipeline systems, enabling precise shut‑off and stable control. It is an important control component in modern sanitary fluid conveying systems.
The product is precision‑manufactured from high‑quality 304 or 316L sanitary stainless steel. The handwheel drives the stem to move up and down, causing the disc to engage or disengage from the seat, thereby opening or closing the media passage. The globe valve offers excellent sealing and regulating performance, suitable for controlling liquids, gases, steam, and high‑purity fluids.It effectively reduces leakage and improves system operational safety.Cutoff valve
The product features sanitary tri‑clamp (quick‑connect) connections Cutoff valve, allowing fast installation, disassembly, and maintenance without specialized tools, greatly improving equipment maintenance efficiency. Both internal and external surfaces are mechanically mirror‑polished or electropolished, providing smooth, dead‑leg‑free fluid contact surfaces that meet international hygiene standards including FDA, GMP, 3‑A, and EHEDG, and support CIP online cleaning and SIP online sterilization.
With excellent corrosion resistance, reliable sealing performance, and convenient maintenance, the stainless steel sanitary manual tri‑clamp globe valve is widely used in various high‑cleanliness fluid control systems.304 Cutoff valve
Thestainless steel sanitary Cutoff valve mainly consists of the valve body, disc, stem, handwheel, bonnet, and 304 Cutoff valve tri‑clamp connection ends.
During operation:
Rotate the handwheel
The handwheel drives the stem to move up and down
The stem pushes the disc to lift or lower
The disc lifts off the seat → media passage opens
Turn the handwheel in reverse
The disc presses against the seat → media flow stops
This achieves opening, closing, and flow regulation of the fluid. The entire process is simple to operate, with smooth opening/closing and reliable sealing.
Accessories
- Valve body: Made of AISI 304 or 316L sanitary stainless steel
Disc:Precision-machined from 304 or 316L stainless steel
Stem:Made of high-strength stainless steel
Handwheel:Made of engineering plastic or stainless steel
Seals: EPDM, Silicone, PTFE, FKM and other food-grade sealing materials
Surface treatment: Internal and external surfaces mechanically mirror-polished or electropolished
- Structural Design：Straight-through globe valve structure with a well-designed flow path, smooth opening/closing, and easy flow regulation.
- Sealing Performance：High-performance sanitary sealing structure ensures tight opening/closing with zero leakage.
- Core Function：Opening, closing, throttling, and flow regulation of sanitary fluids.
- Application Grade：Food grade, dairy grade, pharmaceutical grade, bioengineering grade, and fine chemical grade.
- Specification Compatibility：Supports DIN, SMS, ISO, 3A, IDF and other international sanitary standard interfaces.
- Certification Level：Meets FDA, GMP, 3-A, EHEDG and other international hygienic specification requirements
- Installation：Sanitary tri-clamp connections for quick installation, disassembly, and maintenance
- Customization Services：Supports different materials, different sealing materials, different sizes, and non-standard product
customization. Optional locking handwheel, valve position indicator, and special surface treatment - Control Capability：Suitable for on/off control, throttling regulation, and process flow switching in sanitary fluid systems.
Digital advantages
CNC Precision Manufacturing: Produced on CNC machining centers to ensure machining accuracy of the valve body and sealing surfaces.
Automated Mirror Polishing: Fluid contact surfaces are processed using automated polishing equipment, ensuring consistent sanitary surface roughness.
Full‑Process Quality Inspection: Supports material testing, dimensional inspection, seal testing, pressure testing, cycle life testing, and complete valve performance testing.
Standardized Production Management: Uses a digital production management system for full‑process quality traceability, improving product consistency and batch delivery capability.
Customization Capability: Supports project‑based design and rapid non‑standard specification customization to meet different process requirements in food, dairy, pharmaceutical, bioengineering, and fine chemical industries.
- Sanitary Tri-Clamp Connection Design
- F:Tri-Clamp quick-connect structure
A:Fast installation and disassembly without complex tools
B:Reduces maintenance time, improves production efficiency
- High-Sealing Globe Valve Structure
- F:Precision disc and seat sealing design
A:Tight opening/closing, excellent sealing performance
B:Effectively prevents media leakage, ensures production safety
- High-Quality Sanitary Stainless Steel Material
- F:Made of 304/316L sanitary stainless steel
A:Excellent corrosion resistance, high mechanical strength
B:Extends equipment service life, reduces maintenance costs
- CIP/SIP System Compatibility
- F: Suitable for online cleaning and online sterilization
A:Equipment can be cleaned without frequent disassembly
B:Improves production efficiency, meets high-cleanliness production requirements
