Stainless Steel Ferrule Tri Clamps Female Thread Male Shaft Adaptor

JN-FL-23-1001-1
Size: DN15–DN100.
Grade: SS304/SS316L.
Standard: DIN, SMS, 3A.
Working pressure: 0.6–2.5 MPa.
Test pressure: 3.8 MPa.
Temperature Range: -20°C to 180°C.
PTFE seals: chemical resistance.
Viton seals: high-temperature sealing durability.
Quantity:
Contact Now
Stainless Steel Ferrule Tri Clamps Female Thread Male Shaft Adaptor
Stainless Steel Ferrule Tri Clamps Female Thread Male Shaft Adaptorare sanitary pipeline connectors specifically designed for the food and beverage, biopharmaceutical, dairy, brewing, daily chemical, and fine chemical industries. The product is primarily used for connecting and converting sanitary piping systems with threaded equipment, valves, instruments, and related accessories, achieving rapid transitions and stable seals between different connection methods.
Made of high-quality 304 or 316L sanitary stainless steel, the product features a standard sanitary quick-connect interface on one end and a high-precision internal thread structure on the other, enabling reliable connections with various standard threaded equipment. The compact design facilitates easy installation and disassembly, effectively improving equipment maintenance efficiency and system operational stability.Female Thread Adaptor
The fluid contact surface undergoes precision mechanical polishing or electrolytic polishing, resulting in a smooth, dead-angle-free surface that effectively reduces the risk of media residue and bacterial growth, meeting the stringent requirements of the food, pharmaceutical, and bioengineering industries for sanitary fluid transport systems.
The equipment supports CIP (Clean-in-Place) online cleaning and SIP (Standardized-in-Place) online sterilization, and can be widely used in various sanitary piping systems, storage tank equipment, filling systems, and automated fluid transport production lines.ferrule adaptor
1.2 Product Comparison
Our stainless steel sanitary quick-connect internal threaded fittings are superior to traditional industrial connectors in all aspects of hygiene, installation efficiency, sealing performance, and corrosion resistance.Tri Clamps Adaptor
Compared to ordinary industrial threaded fittings: Utilizes a sanitary mirror-polished finish; eliminates internal dead zones; meets food and pharmaceutical industry standards; supports CIP (Clean-In-Place) and SIP (Sterilize-In-Place) online cleaning.
Compared to traditional welding connections: No on-site welding required; faster installation; easier maintenance; reduced construction costs.
Compared to ordinary flange connections: More compact structure; higher installation efficiency; easier disassembly and assembly; reduced equipment downtime.
Compared to carbon steel fittings: Stronger corrosion resistance; less prone to rust; longer service life; lower maintenance costs.

Working Principle

Stainless Steel Ferrule Tri Clamps Female Thread Male Shaft Adaptor of a quick-connect end, an internal threaded end, a sealing area, and a connecting body.
During installation: The pipeline connects to the connector through the quick-connect interface; the clamp tightens the sealing ring to form a reliable seal; the internal threaded end connects to the external threaded interface of the equipment; a stable sealing structure is formed at the connection point; fluid is continuously transported through the internal flow channel of the connector; a safe connection between the pipeline system and the equipment is achieved.
The entire transport process features low flow resistance, stable operation, and reliable sealing.
This structure can operate stably for a long time and is particularly suitable for high-cleanliness sanitary fluid transport processes.

Accessories

This stainless steel sanitary quick-connect internal thread connector mainly consists of the connector body, quick-connect end, internal thread interface, sealing contact surface, and surface treatment layer.
 Component & Material Table
  • Connector Body: Precision manufactured using AISI 304 or 316L sanitary grade stainless steel.
  • Quick-Connect End: Adopts a standard sanitary grade clamp interface structure design.
  • Internal Thread Interface: Manufactured using high-precision CNC turning.
  • Fluid Contact Surface: Made of sanitary grade stainless steel and mirror polished.
  • Surface Treatment: Both inner and outer surfaces are treated with mechanical polishing or electrolytic polishing processes.
Product Parameter Details
  • Specification Range: DN15～DN150
  • Working Pressure:0～16Bar
  • Working Temperature: -20℃～180℃
  • Material:304, 304L, 316L
  • Surface Treatment: Ra≤0.8μm mirror polished
  • Connection Method: Quick-connect × Internal Thread
  • Thread Standard: BSP, BSPT, NPT, DIN
  • Applicable Media: Food, beverages, dairy products, pharmaceuticals, fermentation broths, and clean fluids

Digital advantages

  • 1. Standardized Manufacturing: Produced using CNC machining equipment to achieve standardized dimensional control.

  • 2. Automated Polishing Process:Achieves uniform and stable surface roughness control.

  • 3. International Standard Compatibility: Supports compatibility with international standards such as DIN, SMS, ISO, and 3A.

  • 4. Full-Process Quality Inspection: Supports material inspection, dimensional inspection, thread inspection, and surface quality inspection.

  • 5. Customized Production Capability: Supports project-based design and non-standard specification customization.

Stainless Steel Ferrule Tri Clamps Female Thread Male Shaft Adaptor

Feature (F)、Advantage (A)、Benefit (B)
  1. Sanitary Stainless Steel Materiall:
  • F: The main body is made of 304/316L sanitary stainless steel.
  • A:Excellent corrosion resistance and long-term stable operation.
  • B: Extends product lifespan and reduces maintenance costs.
  1. Quick-Connect Technology:
  • F: Adopts a standard sanitary quick-connect structure.
  • A:  Quick installation, no complex construction required.
  • B: Shortens installation time and improves work efficiency.
  1. High-Precision Thread Machining
  • F:Manufactured using CNC precision machining technology.
  • A:Ensures thread fit accuracy and sealing stability.
  • B: Reduces leakage risk and improves system reliability.
  1. Sanitary Structural Design:
  • F: Mirror-polished fluid contact surfaces, eliminating sanitary dead corners.
  • A:: Supports CIP online cleaning and SIP online sterilization.
  • B:Effectively improves system cleanliness and production safety.

Stainless Steel Ferrule Tri Clamps Female Thread Male Shaft Adaptor

Product Type：Sanitary Stainless Steel Clamp Female Thread Adapter
Structure Type：Clamp × Female Thread Connector
Material：AISI 304 / 316L Stainless Steel
Connection Type：Clamp × Female Thread
Thread Standard：BSP / BSPT / NPT / DIN
Size Range：DN15 ~ DN150
Working Pressure：0 ~ 16Bar
