Stainless Steel Industrial Female Threaded Equal Tee for Piping

JN-FT-23 1012
Size: Standard sizes from 1/8" to 4" (DN6 to DN100), with custom sizes available on request.
Grade: SS304 / SS316L (316L recommended for corrosive industrial environments).
Standard: ASME B16.11, MSS SP-79, BS 3799, JIS B2316 (forged pipe fitting standards).
Working pressure: Up to 3000LB / 6000LB, depending on size and material grade.
Test pressure: 1.5 times the working pressure (hydrostatic test).
Temperature range: -20°C to 232°C (-4°F to 450°F) for SS316L, suitable for most industrial fluids.
PTFE seals: Available as an optional sealing component, offering excellent chemical resistance and a temperature range of -200°C to 260°C.
Viton seals: Available as an optional sealing component, ideal for high-temperature and oil-resistant applications, with a temperature range of -20°C to 200°C.
Quantity:
Contact Now
Stainless Steel  Industrial Female Threaded Equal Tee for Piping

Stainless Steel  Industrial Female Threaded Equal Tee for Pipingis a T-shaped forged stainless steel pipe fitting Threaded tee withthree female threaded ports of the same size.It is mainly used in industrial piping systems, installed at positions requiring fluid diversion, confluence or direction change, such as pipe branches or connections between main and branch pipes, to distribute fluid from the Stainless tee  main pipe to two branches or combine flows from two branches into the main pipe. It is available in 304 and 316L stainless steel, with thread standards including NPT and BSPT,and is widely applied in chemical, petroleum, water treatment and other industrial pipelines demanding strength and corrosion resistance.

Our product is the Stainless Steel  Industrial Female Threaded Equal Tee for Piping.Unlike ordinary fittings, it featuressolid forgingandhigh-strength stainless steelfor better pressure resistance and durability. Our products stand out with precision CNC threads,strict dimensional accuracy,andpremium 304/316L materials.We carry out 100% pressure testing to ensure no leakage, offering more stable performance, longer service life, and higher reliability than most similar products in the market.


Accessories

Component & Material Table

  • Tee Body: 304/316L Stainless Steel (industrial-grade forging)
  • Threaded Port: 304/316L Stainless Steel (precision CNC threading)
  • Sealing Element: PTFE/EPDM (industrial-grade, corrosion-resistant)
  • Surface Finish: Pickling & passivation (standard); Polished (optional)

Product Parameter Details

  • Material: Main body: 304/316L stainless steel; Seals: industrial-grade PTFE/EPDM
  • Structure Form: Equal tee, female threaded connection; full-forged one-piece structure
  • Pressure Rating: PN16/PN25/3000PSI (working pressure); Test pressure: 1.5× working pressure
  • Function: Fluid diversion, media merging, flow direction switching in industrial piping systems
  • Grade Classification: Industrial grade (for chemical, petroleum, water treatment); no food/pharma hygiene-grade option
  • Specification Match: Standards: ASME B16.11, MSS SP-79, BS 3799; Thread standards: NPT, BSPT; Size range: 1/8"–4"
  • Certification Grade: Safety certification: CE, ISO 9001; Material test reports (MTR) available
  • Installation Direction: Horizontal/vertical installation (no flow direction restriction); accessible for maintenance
  • Customization Service: Custom size (5"+), special seal material (Viton), heavy-wall forging; sample support for testing
Stainless Steel  Industrial Female Threaded Equal Tee for Piping

1. Raw Material:

  • F: 100% virgin 304/316L stainless steel for tee body; industrial-grade PTFE/EPDM seals
  • A: Excellent corrosion resistance; high structural strength; no material contamination
  • B: Safe for chemical, petroleum & water treatment applications; avoids media pollution risks; extends service life

2. Processing Technology:

  • F: Full one-piece forging; precision CNC threading; pickling & passivation surface treatment
  • A: Uniform wall thickness; tight dimensional accuracy; no welding dead corners
  • B: Reduces leakage risks; easy installation & maintenance; prevents pipeline blockages

3. Structure Feature:

  • F: Equal tee design; female threaded connection (NPT/BSPT); three ports of identical size
  • A: Flexible fluid diversion/merging; stable flow distribution; compatible with standard pipe systems
  • B: Cuts installation downtime; adapts to complex pipeline layouts; minimizes operational errors

4. Core Accessory Feature:

  • F: Precision-machined threaded ports; heavy-duty forged body; optional heavy-wall design
  • A: Leak-free sealing; smooth thread engagement; high pressure resistance
  • B: Low maintenance frequency; stable performance in high-pressure conditions; reduces replacement costs

5. Seal Ring Feature:

  • F: Industrial-grade PTFE/EPDM seals; optional Viton seal for high-temperature use
  • A: Excellent sealing performance; wide temperature adaptability; wear resistance
  • B: Adapts to -20°C~232°C working conditions; prevents medium leakage; avoids seal aging failures

Stainless Steel  Industrial Female Threaded Equal Tee for Piping

Interface Mode：Female threaded connection (NPT/BSPT standard); customizable size and thread type
Production & Processing Method：Full one-piece forging shaping; precision CNC threading; no welding dead corners
Surface Treatment：Pickling & passivation (standard); electrolytic polishing (optional); industrial-grade anti-corrosion treatment
Raw Material Processing Method：Tee body: 304/316L stainless steel forging (high structural density, no porosity); sealing elements: precision molding
Operation Mode：Passive pipe fitting (no actuation required); installed via threaded connection
Seal Ring Material Options：Industrial-grade PTFE, EPDM, Viton (FKM); suitable for high-temperature/corrosive applications
Sealing Method：Threaded sealing with PTFE/EPDM gasket; precision thread fit for leak-free performance
