Stainless steel sanitary three-way manual quick-install ball valve

JN-3WBLV-1001
Size：1/2", 3/4", 1", 1-1/2", 2", 2-1/2", 3", 4" (customized for special requirements)
Grade：ASTM A240 304; ASTM A240 316L
Standard：DIN 11851 (German standard), SMS 1145 (Swedish standard), 3A (American sanitary standard), ISO 2852 (international standard)
Working pressure: PN10–PN16 (10–16 bar);
Test pressure: 1.5× working pressure (hydrostatic test)
Temperature Range：PTFE seals: -20℃ ~ 180℃; EPDM seals: -40℃ ~ 120℃; Viton seals: -20℃ ~ 200℃
Quantity:
Contact Now
Stainless steel sanitary three-way manual quick-install ball valve

OurStainless steel sanitary three-way manual quick-install ball valve—a premium Sanitary Valve, reliable Ball Valve, versatile Three-way Valve, user-friendly Manual Valve, durable Steel Valve, and efficient Quick-install Valve—is a hygienic, manually operated fluid control valve featuring clamp-type quick-connect ends and polished inner walls. Designed for flexible flow management in sanitary process pipelines, this Sanitary Valve,Ball Valve,Three-way Valve,Manual Valve,Steel Valve, and Quick-install Valve is typically installed at pipeline junctions, mixing points or diversion nodes in food, beverage, pharmaceutical and dairy industries, where it serves to switch flow directions, merge two fluid streams or divert one stream into two paths. Its main types include L-port valves for flow direction switching and T-port valves for flow merging or diversion; both variants are top-tierSanitary Valves, Ball Valves, Three-way Valves, Manual Valves, Steel Valves and Quick-install Valves available in 304 or 316L stainless steel grades to meet varying corrosion resistance needs.

OurStainless steel sanitary three-way manual quick-install ball valve—a high-performance Sanitary Valve, robust Ball Valve, adaptable Three-way Valve, easy-to-operate Manual Valve, corrosion-resistant Steel Valve, and hassle-free Quick-install Valve—differs from ordinary Ball Valves in its sanitary-grade polished inner cavity that eliminates medium residue (meeting food/pharma standards), quick-clamp connection that defines a true Quick-install Valve, and three-way L/T port structure that makes it a versatile Three-way Valve.Unlike ordinary valves that only focus on basic on-off control with threaded/flanged connections, this premium Sanitary Valve and durable Steel Valve delivers flexible flow diversion and merging. Compared with competitors’ products, our Stainless steel sanitary three-waymanual quick-install ball valve—a reliable Manual Valvebuilt for precision operation—stands out with 100% pure 304/316L stainless steel material, 0-90° smooth precision handle operation, and strict pre-delivery pressure/leak tests. This top-tier Sanitary Valve, Ball Valve, Three-way Valve, Manual Valve, Steel Valve, and Quick-install Valve ensures longer service life and more stable performance in high-frequency hygienic applications.


Accessories

 Component & Material Table
  • Valve Body & Ball：304/316L Stainless Steel (sanitary-grade forging)
  • Valve Seat & Seal Ring：PTFE/EPDM (food-grade, corrosion-resistant)
  • Manual Handle：304 Stainless Steel/Aluminum Alloy (anti-slip)
  • Quick-clamp Fitting：304/316L Stainless Steel (polished finish)
  • Valve Stem：304/316L Stainless Steel (wear-resistant)
Product Parameter Details
  • Material：Main body: 304/316L stainless steel; Seals: food-grade PTFE/EPDM; Handle: 304 SS/aluminum alloy
  • Structure Form：Standard: three-way L/T port, clamp-type quick-install; Optional: jacketed structure for temperature control
  • Pressure Rating：PN10/PN16; 150PSI (working pressure); Test pressure: 1.5× working pressure
  • Function：Flow direction switching, media merging, fluid diversion; on-off control for hygienic pipelines
  • Grade Classification：Hygiene grade: 3A/DIN 11851; Industry grade: sanitary-grade (for food/pharma), no industrial-grade option
  • Specification Match：Standards: DIN (German), SMS (Swedish), 3A (American), ISO (international); Size range: 1/2"–4"
  • Certification Grade：Hygiene certification: 3A, FDA; Safety certification: CE, ISO 9001
  • Installation Direction：Horizontal/vertical installation (no flow direction restriction; handle upward for easy operation)
  • Customization Service：Custom size (5"+), special seal material (Viton), jacketed structure; sample support for testin
Stainless Steel Sanitary Three-way Manual Quick-install Ball Valve

Feature (F)、Advantage (A)、Benefit (B)
  1. Raw Material:
  • F: 100% virgin 304/316L stainless steel for valve body & ball; food-grade PTFE/EPDM seals
  • A:Corrosion resistance; no material contamination; compliance with hygienic standards
  • B: Safe for food, pharmaceutical & dairy applications; avoids media pollution risks
  1. Processing Technology:
  • F: Full cavity mirror polishing (Ra≤0.8μm); one-piece forging; no welding dead corners
  • A: No medium residue; easy cleaning & sterilization; high structural strength
  • B: Reduces cleaning time & labor costs; meets CIP/SIP requirements; prevents pipeline blockages
  1. Structure Feature:
  • F: L/T three-way port; clamp-type quick-install connection; 0-90° rotary handle
  • A:Flexible flow diversion/merging; 50% faster assembly/disassembly; precise flow control
  • B: Cuts installation downtime; adapts to complex pipeline layouts; minimizes operational errors
  1. Core Accessory Feature:
  • F: Precision-machined stainless steel ball (zero clearance fit); anti-slip aluminum handle
  • A: Leak-free sealing; smooth operation without jamming; long service life
  • B:Low maintenance frequency; stable performance in high-frequency use; reduces replacement costs
  1. Seal Ring Feature:
  • F:Integrated PTFE seal with EPDM backup ring; high-temperature resistant
  • A:Excellent sealing performance; wide temperature adaptability; wear resistance
  • B:Adapts to -20℃~180℃ working conditions; prevents medium leakage; avoids seal aging failures

Stainless steel sanitary three-way manual quick-install ball valve

Interface Mode：Clamp-type quick-install (DIN/SMS/3A/ISO standard); customizable threaded/flanged ends
Production & Processing Method：Full CNC precision machining; one-piece forging shaping; no welding dead corners
Surface Treatment：Inner cavity mirror polishing (Ra ≤ 0.8μm); outer surface electrolytic polishing/passivation; sanitary-grade anti-corrosion treatment
Raw Material Processing Method：Valve body & ball: 304/316L stainless steel forging (high structural density, no porosity); accessories: precision casting/stamping
Operation Mode：Standard manual (ergonomic rotary handle); customizable pneumatic/electric actuation
Seal Ring Material Options：Food-grade PTFE, EPDM, Viton (FKM); FDA/3A certified for hygienic applications
Sealing Method：Center seal (zero clearance fit between valve ball and seat); high-precision surface sealing for leak-free performance
