Stainless Steel Saniatry Top Quality Pneumatic Membrane Valve With SS Actuator

The gasket for the diaphragm valve perform as an important part in controling the flow rate. Our gasket is qualified with 3A certificate. The valve is clean, sanitary, easy remaintenance, easy operation, no-leaking.

Aseptic design

The valves are suitable for applying in high flow rate, high corrosivity, high viscosity fluid.

mooth contacting surface, non retention dead angle

easy disassembly, easy maintainenance, easy to clean, CIP

Unique diaphragm type actuator which prolong the diaphragm service life effectively.

Body: casting or forging materials
Gasket: EPDM, PTFE, teflon ( FDA approved raw material)
Size range: 1/2”, 3/4”, 1”, 1 1/4”,1 1/2”, 2”  Larger sizes are provided according to customers' requirements
Standard: 3A, SMS, ISO, DIN,
Connection: clamp , weld, ect
Material grade: SS304 or SS316L

Application: Pharmacy, beer, food, dairy, beverage, cosmetic, chemical industry
