Stainless Steel Sanitary High Quality Manual Mini Sample Valve
The valve body: SS304 or SS316L
Long service life
Easy to sterilize
Sampling work can be done any time during production, no need to stop production.
Sterilization by alcohol or steam
Material sealed by diaphragm directly
No second -time contamination, bulk or mini sample allowed
Inside surface :Ra0.5um
Outside surface0.8um
Valve head: SS304
Gasket: Silicone, EPDM
Max. pressure: 1000kpa ( valve close)
Max. pressure: 500Kpa for silicone ( valve open)
1000Kpa for stainless steel part ( valve open)
Max. temperature: 130 degree Normally we change the gasket after 100 times sterilization.
