Stainless Steel Sanitary Water Treatment Filter Equipment With SS Mesh

Y type Filters are used for filtering the solid particles in liquid. The inlet and outlet of Y type filter is in the same line. So it is widely used for pipeline. The filter housing and filter elements are seperate. So we can easily clean the filter element .There is non dead angle in Y filter, so we can clean the Y filter easily and completely.

Reasonable structure

Good  filtration and sealing ability

Small pressure loss

Easy maintenance

Max operation pressure:1.0mpa
Max operation temperature: 120 C
Filtering accuracy: 0.5mm, 1mm,2mm,3mm,5mm,8mmMax flow rate: 15T/H
Connection end: welded, tri-clamped. Threaded, union end
Filter element :30#, 40#, 60#, 80#,100#, 120#, 150#,  200#, 240#, 260#, 300#, 320#, 360#, 400#
Size: 1”-4”
Material: SS304, SS316L
Inside Ra: 0.4um
Outside surface Ra:0.8um
Seal: EPDM, silicone,
Application: Food, beverage, dairy, pharmacy, chemical or any food processing industries
