SS Food Grade Anti-Leakage RJT Pneumatic Mini Stop Reversing Valve

SS Food Grade Anti-Leakage RJT Pneumatic Mini Stop Reversing Valve


    Stainless Steel Sanitary Diversion Valve, Stainless Steel Sanitary Stop Single Seat Valve, Stainless Steel Sanitary Flow Diversion Valve, Stainless Steel Sanitary Reverse Direction Valve, Stainless Steel Sanitary Regulating Control Valve, Stainless Steel Mix Proof Valve

SS Food Grade Anti-Leakage RJT Pneumatic Mini Stop Reversing Valve

Flow diversion valve
Stainless steel shutoff / flow diversion valve
The valve is used to stop the liquid or change the flow direction in the system.
Features:

Open support bracket which separates the actuator and valve body, the design makes shaft seal checking easily
Spherical valve body assures ideal fluidity
Dealing material softly
Ultra-thick spherical design avoid the deshape caused from heating stress
All the contacting parts can be cleaned together or alone
Temperature: -10 degree to 120 degree
High precise casting body
Pressure: 10bar
Working mode: Manual, pneumatic type
Gasket: EPDM, silicone
Easy cleaning , easy maintenance

Valve body type: 20, 30, 21, 22, 31, 32 type
Connection mode: Clamped, welded, etc
Specification: 1"-4", DN25-DN100
Material quality: SUS304, SUS316L
Surface: Mirror polishing, or sand blasting type

inner surface: 0.4Ra
Outer surface : 0.8Ra
Application: Food, beverage, dairy, pharmacy, chemical or any food processing industries
